PVE Vacuum Elevator
PVE residential elevators are unique to the home elevator market. These sleek and modern elevators do not require the use of any mechanical lifting devices such as ropes, cables, pulleys, gears, or hydraulics. By utilizing the power of air through a vacuum pump located at the top of the unit, the passenger cab can be elevated up and down within a sealed vacuum chamber.
PVE home elevators have been on the market for over 20 years and have a proven track record of safety, reliability, and durability. The maintenance and cost required of a pneumatic elevator is far less than that of a traditional elevator. Since there are no moving parts or hydraulics, the only real maintenance task is the replacement of the main vacuum seal after 15,000 rides.
PVE home elevators are available in four models that vary in size and capacity. The three cylindrical models are the PVE30, PVE37, and the PVE52. The PVE Cube model operates in the same way as the others, but it features a four-sided square vacuum chamber instead of circular. The below chart compares all four models and the differences between them.
Compare PVE Models & Features
| PVE30 | PVE37 | PVE52 | The Cube | |
|---|---|---|---|---|
| Number of Passengers | 1 | 2 | 3 | 2 |
| Supported Weight | 350lb. | 450lb. | 525lb. | 450lb. |
| External Diameter | 30" | 37" | 52 11/16" | 36"x36" |
| Wheelchair Accessible? | Unavailable | Unavailable | Available | Unavailable |
Features
- Modern styling with clear 360 degree window panels to maintain visibility in any direction
- No hoistway, machine room, or pit required, saving you money on construction
- Self-supported tower
- 350-525 lb. weight capacity
- Through the floor or balcony mount landings
- SMART home integration available
- Left or right-hand opening door
Safety Features
- Mechanical emergency safety brake system
- Emergency battery backup in case of power failure
- Slow descent system in case of power failure
- Smooth air ride technology
- Interior LED lighting
- Nonskid platform
- Earthquake brackets available
Options
- Available in a variety of colors to match your home's decor. Click here to see available color options
- Available in 3 sizes, including the PVE52 which can accommodate wheelchair users
- Cabin seat available
- Solar panel package available
- Split unit configuration available
- Remote control option available
- Clear or tinted polycarbonate panels
- Custom right-hand door option available
- In cab phone option
